OVERVIEW
Deluxe offers the complete package: an inline shock with all the tuning options needed for precise ride performance, light weight, and bottom-out control for aggressive riding. With an independent Low Speed Compression adjustment, riders can optimize Deluxe Ultimate's performance for their riding style.
FEATURES
- NEW Lighter compression tunes let you dial in the perfect balance between efficiency and descending capability for your bike
- Ultimate model features independent Low Speed Compression and Low Speed Rebound adjustments and easy access lever to go from Open to Firm/Lock
- NEW Electric Red Signature colorway
- NEW bottom-out system prioritizes a more open compression and air spring feel enhancing control and eliminating unwanted noise
- Maximize testing and tuning efforts with consistent "feel" between DLX ULT, DLX SEL+, DLX SEL at the same tune
- DebonAir+ Linear XL air can offers all the tuning potential and range in one compact unit
SPECIFICATIONS
Model ID: RS-DLX-ULT-C2
| Eye to eye / Stroke | 165x37.5(TR), 165x40(TR), 165x42.5(TR), 165x45(TR), 185x47.5(TR), 185x50(TR), 185x52.5(TR), 185x55(TR), 190x37.5, 190x40, 190x42.5, 190x45, 205x57.5(TR), 205x60(TR), 205x62.5(TR), 205x65(TR), 210x47.5, 210x50, 210x52.5, 210x55, 230x57.5, 230x60, 230x62.5, 230x65 |
|---|---|
| Damper Type | RCT |
| Rebound tune | R25, R55, R85 |
| Compression tune | C22, C26, C30, C34, C37, C40 |
| Lockout force | X4, X6, X8 |
| Shaft Eyelet | Bearing, Standard, Trunnion |
| Body Eyelet | Bearing, No Bushing, No Bushing - 90 Deg Rotation, Standard, Standard - 90 Deg Rotation |
| E-Bike Approved | E-bike Approved |
| Bottom Out | n/a |
| High Speed Tune | n/a |
| Weight (g) | 378 |
| Weight Based On | 210x55, no hardware installed |
