FEATURES
- Hookless rim design enhances overall durability and offers a wide 22.4mm inner rim width without adding weight
- Optimized carbon layup features high tensile strength carbon fiber placed at the most crucial points for a stiff, strong but lightweight wheel
- Low friction hub with precision machined internals eliminates excessive bearing load, reducing bearing friction, lowering rolling resistance and minimizing power loss
- Dynamic Balanced Lacing (DBL) ensures spokes are set for optimal tension when pedaling, resulting in enhanced durability and transmission efficiency
- The enlarged DBL hub flange increases spoke bracing angles, boosting overall torsional/transmission and lateral stiffness for better power transfer
SPECIFICATIONS
| Rim Material | Carbon |
| Rim Type | Hookless Clincher |
| Tubeless | Giant Tubeless System (rim tape and valve kit included) |
| Rim Height | 50mm |
| Rim Outer Width | 26mm |
| Rim Inner Width | 22.4mm |
| ETRTO | 622-22 |
| Front Hub | Giant Low Friction Hub, Centerlock |
| Rear Hub | Giant Low Friction Hub, Ratchet Driver, Centerlock |
| Hub Compatibility | Shimano 11 / SRAM XDR 12 / Campagnolo |
| Bearing | Precision Sealed Cartridge |
| Front Axle | 100x12 Thru Axle |
| Rear Axle | 142x12 Thru Axle |
| Spokes (Front) | SAPIM CX-Ray |
| Lacing (Front) | DBL Disc, 24H |
| Spokes (Rear) | SAPIM CX-Ray |
| Lacing (Rear) | DBL Disc, 24H |
| Nipple Type | Alloy |
| Warranty | 2 years |
| Weight (Pair) | 1518g with Shimano freehub |
| WheelSystem Weight Limit | 285 lbs / 129 kg |
