CLIMB, CORNER AND DESCEND WITH SPEED AND EFFICIENCY. FROM THE MOUNTAINS TO THE FLATS, IN ALL TYPES OF CONDITIONS, THIS LIGHTWEIGHT COMPOSITE ROAD RACER TAKES YOU TO THE NEXT LEVEL.
KEY PERFORMANCE FACTORS
Class-leading efficiency
With an outstanding stiffness-to-weight ratio and updated aero tube shaping, this frameset is engineered for superior climbing capabilities, aerodynamic efficiency and sprint stiffness for race-winning performance.
Advanced aerodynamics
This is where the TCR’s most quantifiable gains can be found compared to previous generation models. Every tube shape was analyzed, engineered and tested to create an overall structure with significantly lower drag at a wider range of yaw angles.
Total control
Integrated disc brakes deliver smooth, powerful stopping power and modulation for added control in variable weather and road conditions. Flat mounts and new thru-axles boost stiffness and improve overall handling, while added frame and fork clearance allows for larger diameter tires up to 32mm.
SPECIFICATIONS
-
Sizes
XS, S, M, M/L, L, XL
-
Colors
Black Diamond, Blackcurrant, Carbon Satin, Gloss Carbon/Chrome, Metallic Army Satin, Orion Nebula, Phantom Green
-
Frame
Advanced-Grade Composite, disc
-
Fork
Advanced-Grade Composite, full-composite OverDrive 2 steerer, disc
-
Shock
N/A
-
Handlebar
Giant Contact SL XS:40cm, S:40cm, M:42cm, M/L:42cm, L:44cm, XL:44cm
-
Grips
Stratus Lite 2.0
-
Stem
Giant Contact SL XS:80mm, S:90mm, M:100mm, M/L:110mm, L:110mm, XL:120mm
-
Seatpost
Giant Variant, composite, -5/+15mm offset
-
Saddle
Giant Fleet SL
-
Pedals
N/A
-
Shifters
Shimano 105 ST-R7120
-
Front Derailleur
Shimano 105 FD-R7100
-
Rear Derailleur
Shimano 105 RD-R7100
-
Brakes
Shimano 105 hydraulic BR-R7170, Shimano RT64 rotors [F] 160mm, [R] 140mm
-
Brake Levers
Shimano 105 hydraulic ST-R7120
-
Cassette
Shimano 105, 12-speed, 11x34
-
Chain
KMC X12
-
Crankset
Shimano FC-R7100, 36/52 (XS/S: 170mm, M/ML: 172.5mm)
-
Bottom Bracket
Shimano PressFit Road 86.5mm
-
Rims
vSprint carbon, 50mm depth
-
Hubs
vSprint Straight-pull hubs, 36T star ratchet, centerlock rotor mounts
[F] 100x12mm thru-axle, [R] 142x12mm
-
Spokes
vSprint stainless steel, bladed
-
Tires
Giant Course 1, tubeless, 700x25c (26.5mm), folding
-
Extras
tubeless prepared, 32mm max tire size
-
Weight
≈ 7.95kg (Size S)
*All specifications and prices listed are subject to change without notice.
