Highlight

GO LONG. GO FAST. SUPERLIGHT AND SILKY SMOOTH, THE FLAGSHIP SERIES OF THE NEW DEFY RANGE IS BACK TO RECLAIM ITS TITLE AS THE PINNACLE OF ENDURANCE ROAD. IT’S THE PERFECT CHOICE FOR THE SPORTIVE OR GRAN FONDO THAT’S CIRCLED ON YOUR CALENDAR.

KEY PERFORMANCE FACTORS

Functional Simplicity

Free of cumbersome gimmickry, the frameset is one of the lightest in its category. With a perfect balance of high-performance reactivity and all-day comfort, it offers a “less is more” experience for modern endurance road riding.

Engineered Compliance

Advanced SL-grade composite frame and fork are specifically engineered for endurance road riding, delivering a smooth and efficient ride quality that minimises fatigue on long rides. The new D-Fuse components work together to further absorb road shocks and vibrations.

Total Control

A new Contact D-Fuse handlebar features ergonomic shaping and an 8-degree flare for comfort and control on all-day rides. Wide, hookless carbon rims (22.4mm inner width) are optimised for high-volume tubeless tyres (up to 38mm), and a 36mm rim depth offers stable, predictable handling in crosswinds.

SPECIFICATIONS

Sizes

XS, S, M, M/L, L, XL

Colours

Tiger Red/Dried Chili

Frame

Advanced-grade composite, disc

Fork

Advanced-grade composite, full-composite steerer, disc

Shock

N/A

Handlebar

Giant Contact SL D-Fuse XS:40cm, S:40cm, M:42cm, M/L:42cm, L:44cm, XL:44cm

Grips

Stratus Lite 3.0

Stem

Giant Contact AeroLight XS:80mm, S:90mm, M:100mm, M/L:100mm, L:110mm, XL:110mm

Seatpost

Giant D-Fuse, composite, 14mm offset

Saddle

Giant Approach

Pedals

N/A

Shifters

Shimano 105

Front Derailleur

Shimano 105

Rear Derailleur

Shimano 105

Brakes

Shimano 105 hydraulic, Giant MPH rotors [F]160mm, [R]160mm

Brake Levers

Shimano 105

Cassette

Shimano 105, 11x36

Chain

KMC X12L-1

Crankset

Shimano FC-RS520, 34/50 XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm

Bottom Bracket

Shimano, press fit

Rims

Giant P-R2 Disc wheelset, alloy

Hubs

Giant alloy, 12mm thru-axle

Spokes

Sapim stainless

Tyres

Giant Gavia Fondo 1, tubeless, 700x32c (33.5mm), folding

Extras

fender mount, water bottle cages, factory tubeless set up, 38mm max tyre size

Weight
8.65kg

*All specifications and prices listed are subject to change without notice.

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary by country.

Defy Advanced, Advanced Pro & Advanced SL (5th Gen)

		XS	S	M	ML	L	XL
A	Seattube length	410	445	480	515	535	565
B	Seattube angle (degrees)	74.5	74.0	73.5	73.0	73.0	73.0
C	Toptube length	515	530	545	560	575	595
D	Headtube length	120	140	150	175	195	215
E	Headtube angle (degrees)	70.50	71.75	72.50	72.50	72.50	72.50
F	Fork rake	50	50	50	50	50	50
G	Trail	71.6	63.4	58.6	58.6	58.6	58.6
H	Wheelbase	995.2	994.4	997.7	1010.0	1025.2	1040.4
I	Chainstay length	420	420	420	420	420	420
J	Bottom bracket drop	75	75	75	70	70	70
K	Stack	527	541	558	577	596	615
L	Reach	368.9	374.9	379.8	383.7	392.9	402.0
M	Standover height	705	733	762	796	814	841
N	Handlebar width	400	400	420	420	440	440
O	Stem length	80	90	100	100	110	110
P	Crank length	170.0	170.0	172.5	172.5	175.0	175.0
Q	Wheel size	700C	700C	700C	700C	700C	700C
